Flood Light FLJA20S Wattage 20

---

CODE	DIMENSIONS(mm)	WATTAGE
FLJA20S	184 x 154 x 45	20
FLJA30S	224 x 190 x 42	30
FLJA50S	285 x 240 x 60	50
FLJA100s	338 x 295 x 85	100
FLJA150S	426 x 326 x 86	150
FLJA200S	426 x 326 x 86	200

CODE	DIMENSIONS(mm)	WATTAGE
FLJB250s	515 x 315 x 170	250
FLJB300S	515 x 315 x 170	300

General Specifications

LED	Bridgelux/Osram
LED SIZE	SMD
BODY COLOR	Grey
IP RATING	65
COLOR TEMP	3000/4000/6500K
LUMEN OUTPUT	>2000lm I > 3000lm I >5000lmI >10000lm | >15000lm I >20000lm
MATERIAL	Pressure die cast aluminum enclosure
BEAM ANGLE	120 Deg
MOUNTING	Wall, pole & Surface Mounting
WARRANTY	2 Yrs

General Specifications

LED	Bridgelux/Edison/Seoul/Osram/ Cree
LED SIZE	SMD
BODY COLOR	Black & Grey
IP RATING	65
COLOR TEMP	3000/4000/650ok
LUMEN OUTPUT	>25000lm | >30000lm
MATERIAL	Pressure die cast aluminum
BEAM ANGLE	120 Deg
MOUNTING	Pole /Wall & Surface mount
WARRANTY	2 Yrs

CODE	DIMENSIONS(mm)	WATTAGE
FLJC50	215 x 200 x 50	50
FLJC100	263 x 237 x 53	100
FLJC150	292 x 275 x 60	150
FLJC200	323 x 323 x 55	200
FLJC300	385 x 372 x 75	300
FLJC400	520 x 520 x 70	400

CODE	DIMENSIONS(mm)	WATTAGE
FLJD30	190 x 148 x 35	30
FLJD50	240 x 185 x 35	50
FLJD100	305 x 245 x 35	100
FLJD150	345 x 307 x 35	150
FLJD200	396 x 383 x 58	200

General Specifications

LED	Bridgelux/ Edison / Seoul
LED SIZE	SMD
BODY COLOR	Grey
IP RATING	65
COLOR TEMP	3000/4000/6500K
LUMEN OUTPUT	>2000lm I > 3000lm I >5000lmI >10000lm | >15000lm I >20000lm
MATERIAL	Pressure die cast aluminum enclosure
BEAM ANGLE	120 Deg
MOUNTING	Wall, pole & Surface Mounting
WARRANTY	2 Yrs

General Specifications

LED	Bridgelux/ Osram /Seoul/Edison
LED SIZE	SMD
BODY COLOR	White / Grey
IP RATING	65
COLOR TEMP	3000/4000/6500k
LUMEN OUTPUT	>3000lm | >5000lm I >10000lm | >15000lm | >20000lm
MATERIAL	Pressure die cast aluminum
BEAM ANGLE	60 Deg.
MOUNTING	Wall, pole & Surface Mounting
WARRANTY	2 Yrs
